Product Summary

Use the wall railing concrete formwork as the exterior material
Aluminum alloy residual formwork

The remaining aluminum alloy formwork is the concrete formwork for the wall railings on the outside of the bridge that is used as the exterior material. This allows for early removal of external scaffolding and shortens the construction period.
Not only does it improve safety, but it also prevents concrete from falling off due to deterioration.

Product Features

01
Aesthetics
Aluminum alloys have been used in various civil engineering fields. All of them demonstrate the characteristics of aluminum in facilities where structure and aesthetics are required.
02
Workability

The specific gravity is 1/3 compared to steel products, improving workability.

  • Steel formwork/concrete composite formwork weight 160-175kg/2m unit
  • Aluminum alloy residual formwork weight 50-60kg/2m unit
03
Safety

Aluminum alloy residual formwork has shown excellent performance in the following aspects.

  1. Static loading tests have confirmed that the bending rigidity and static bending strength are comparable to that of conventional concrete wall railings. Additionally, we have confirmed that the remaining aluminum alloy formwork does not fall off or the mating parts break until the point of failure.
  2. Impact performance confirmation experiments have confirmed that the remaining aluminum alloy formwork does not break due to impact loads, and has the ability to prevent concrete fragments from scattering to the back of the formwork.
Impact performance confirmation experiment status, test object destruction status, and concrete scattering amount

concrete specimen

Aluminum + concrete specimen

Destruction status of concrete specimen

Destruction status of aluminum + concrete specimen

Total scattering amount and maximum concrete piece mass graph for concrete specimen and aluminum + concrete specimen

New Technology Registration

Ministry of Land, Infrastructure, Transport and Tourism NETIS Registration No. TH-130004-A (Technical name: Aluminum alloy residual formwork for wall parapet)

Works

Street construction Tokushima East Ring Suehiro/Sumiyoshi Viaduct / Tokushima Prefecture
Street construction Tokushima East Ring Suehiro/Sumiyoshi Viaduct / Tokushima Prefecture
Highway Route 3 III stage steel superstructure (Kannon west construction area) formwork / Hiroshima Prefecture
Highway Route 3 III stage steel superstructure (Kannon west construction area) formwork / Hiroshima Prefecture
Highway Route 127 Stage III steel superstructure (Eba Higashi P133-XNUMX) formwork / Hiroshima Prefecture
Highway Route 127 Stage III steel superstructure (Eba Higashi P133-XNUMX) formwork / Hiroshima Prefecture
